Hioki LCR Meters dan Impedance Analyzers berkisar dari perangkat 1mHz hingga 3GHz untuk disesuaikan dengan berbagai aplikasi dalam pengujian komponen elektronik. 3506-10 adalah pengukur kapasitansi dual-band yang dirancang untuk diintegrasikan dengan mesin perekam otomatis dan penyortir untuk produksi MLCC (kapasitor keramik multi-lapisan).
Basic specifications
| Measurement parameters | C (Capacitance), D (loss coefficient, tan δ), Q (1/tan δ) | |||||
|---|---|---|---|---|---|---|
| Measurement range | C: 0.001 fF to 15.0000 μF, D: 0.00001 to 1.99999, Q: 0.0 to 19999.9 | |||||
| Basic accuracy | (Typ.) C: ±0.14 % rdg., D: ±0.0013 | |||||
| Measurement frequency | 1 kHz, 1 MHz | |||||
| Measurement signal level | 500 mV, 1 V rms | |||||
| Output impedance | 1 Ω (at 1 kHz in 2.2 μF and higher ranges), 20 Ω (in ranges other than the above) | |||||
| Display | LED (six digits, full scale count depends on measurement range) | |||||
| Measurement time | 1.5 ms: 1 MHz, 2.0 ms: 1 kHz (Typ. value. Depends on measurement configuration settings) | |||||
| Functions | BIN (measurement values can be classified by rank), Trigger-synchronous output, Setting configurations can be stored, Comparator, Averaging, Low-C reject (bad contact detection), Chatter detection, Current detection circuit monitoring, Applied voltage value monitoring, EXT. I/O, RS-232C, GP-IB | |||||
| Power supply | Selectable from 100, 120, 220 or 240 V AC ±10 %, 50/60 Hz 40 VA max. | |||||
| Dimensions and mass | 260 mm (10.24 in) W × 100 mm (3.94 in) H × 298 mm (11.73 in) D, 4.8 kg (169.3 oz) | |||||
| Included accessories | Power cord × 1, Instruction manual × 1, Spare fuse × 1 | |||||
