SPECIFICATIONS
OVERVIEW
- Accuracy
- ±3°C or ±5%, typical Percent of the difference between ambient and scene temperature. Applicable 60 sec after start-up when the unit is within 15°C — 35°C and the scene is within 5°C — 120°C.
- Non-Operating Temperature
- -20°C — 60°C (-4°F — 140°F)
- Scene Dynamic Range
- -20°C — 400°C (-4°F — 752°F)
- Spot Meter
- Off / °C / °F. Resolution 0.1°C / 0.1°F
- Thermal Sensitivity/NETD
- 70 mK
- Weight
- 36.5 g
- Dimensions (H x W x D)
- 68 × 34 × 14 mm (2.7 × 1.3 × 0.6 in)
- Phone
- iOS
APP
- Adjustable MSX distance
- 0.3 m — Infinity
- Battery charge monitor
- 0 — 100%
- Capture modes
- Video, Still image, Time lapse
- File Formats
- Still images – radiometric jpeg Video – MPEG-4 (MP4)
- Palette
- Gray (white hot), Hottest, Coldest, Iron, Rainbow, Rainbow HC, Arctic, Lava and Wheel
- Video and Still Image Display/Capture
- Saved as 1440 × 1080
COMPLIANCE & CERTIFICATIONS
- Certifications
- MFi (iOS version), RoHS, CE/FCC, CEC-BC, EN61233
CONNECTIONS & COMMUNICATIONS
- Charging
- Female USB-C (5V/1A)
- Video
- Male Lightning
ENVIRONMENTAL & APPROVALS
- Emissivity Settings
- Matte: 95%, Semi-Matte: 80%, Semi-Glossy: 60%, Glossy: 30%
- Mechanical shock
- Drop from 1.8 m
- Operating Temperature
- 0°C — 35°C (32°F — 95°F) , battery charging 0°C — 30°C (32°F — 86°F)
IMAGING & OPTICAL
- Focus
- Fixed 15 cm — Infinity
- Frame Rate
- 8.7 Hz
- General Description
- Thermal and Visual Cameras with MSX
- HFOV/VFOV
- 55° ±1° / 43° ±1°
- Shutter
- Automatic/Manual
- Thermal Resolution
- 160 × 120
- Thermal Sensor
- Pixel size 12 µm, 8 — 14 µm spectral range
- Visual Resolution
- 1440 × 1080
POWER
- Battery charge time
- 40 min
- Battery Life
- Approximately 1 hr
